ImageWriter II A/C Board Assembly

Description

A/C Board Assembly for the ImageWriter II printer

This board and wiring may be different between an ImageWriter II Model A9M0310 and A9M0320.

Choose One:

EARLY A9M0310 – CBE61-04302 with long wires to the switch (second photo). This is from a very EARLY model only and part of it includes an extension cable to make it all the way to the power switch. Used with the short wired Power Switch.

A9M0310 and A9M0320 – CBE61-04302/04303 with short wires to the switch (first photo). Used with the long wired Power Switch.

* Images are representative and not of the exact part you will receive.
